DESIGNED BY EK
TOGETHER WE EMPOWER YOU TO SHOWCASE YOUR WATER-COOLING SKILLS

Designed to simplify the custom water cooling build process for beginners PC builders who enter the hard tubing water cooling world, the O11D Distro-Plate G1 offers an all in one solution that includes pump, reservoir, simple mounting mechanism, and multiple industry standard G1/4″ threaded inlet and outlets. The placement of these inlets and outlets are perfectly aligned to fit inline with the PC components in order to minimize the number of bends the user has to make in order to create the loop. Able to support 1 CPU, 2 GPUs and up to 2 radiators, custom water cooling has never been so accessible.




Compatible with O11D & O11D XL
| MODEL | LIAN LI O11D DISTRO-PLATE G1 DESIGNED BY EKWB WITH DDC 3.1 PUMP |
|---|---|
| DIMENSIONS | (L) 345 x (W) 131 x (H) 29 mm |
| MATERIAL | ACRYLIC (BODY) PPS-GF30, EPDM O-RINGS, ALUMINUM OXIDE, GRAPHITE (PUMP) |
| COMPATIBILITY | O11D SERIES, O11D XL |
| ADDRESSABLE RGB LED STRIP | 1 (LED COUNT 18 |
| LED POWER CONSUMPTION | 0,3A 5V |
| CPU BLOCK SUPPORT | 1 CPU block |
| GPU BLOCK SUPPORT | UP TO 2 GPU BLOCKS IN SLOT 1 OR SLOT 2 |
| RADIATOR SUPPORT | UP TO 2 X 120/240/360MM RADIATORS UP TO 60MM IN THICKNESS |
| PORT THREAD TYPE | G1/4 |
| MOUNTING HOLE SIZE | M4 (MOUNTING HARDWARE IS INCLUDED) |
| PUMP ELECTRICAL & MECHANICAL PROPERTIES | |
| MOTOR | ELECTRONICALLY COMMUTED MOTOR |
| RATED VOLTAGE | 12V DC |
| POWER CONDUMPTION | 6W |
| MAXIMUM PRESSURE HEAD | 2.6M< |
| MAXIMUM FLOW | 500 L/H |
| MAXIMUM AMBIENT TEMPERATURE | 10-50°C |
| MAXIMUM FLUID TEMPERATURE | 10-60°C |
| POWER CONNECTOR | 4PIN PWM FAN CONNECTOR |
| CABLE LENTH | 50CM |
| TECHNICAL DATA | |
| Reservoir Diameter | 60mm |
| Overall Height | 121mm incl. pump |
| Mounting hole pattern | 50x50mm |
| OPERATIONAL REGIME | |
| PWM DUTY CYCLE | ~ 20-100% |
| DEFULT BEHAVIOR | Runs at 100% duty cycle when no PWM feedback signal is present. |
